Summary: Lenovo Legion T5 30IAS10. Processor family: Intel Core Ultra 5, Processor model: 225F. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5600 MHz. Total storage capacity: 1 TB, Storage media: SSD. Discrete graphics card model: NVIDIA GeForce RTX 5060. Wi-Fi. Power supply: 500 W. Chassis type: Tower. Product type: PC. Weight: 15 kg. Product colour: Black
Vendor Homepage: https://www.lenovo.com/
Name: PC T5-30IAS10 CU5-225F/16GB/1TB 90YA004XRM LENOVO
Category Code: DT
Model: T5 30IAS10
Desktop Computer Family name: Legion
Chassis type: Tower
Colour name: Eclipse Black (Transparent cover) + airflow with ARGB + Inner Decorate Cover
Volume: 30
Product colour: Black
Processor manufacturer: Intel
Processor family: Intel Core Ultra 5
Processor generation: Intel Core Ultra (Series 2)
Processor model: 225F
Processor cores: 10
Processor threads: 10
Processor boost frequency: 4.9
Performance cores: 6
Efficient cores: 4
Performance-core Max Turbo Frequency: 4.9
Efficient-core Max Turbo Frequency: 4.4
Performance-core base frequency: 3.3
Efficient-core base frequency: 2.7
Processor cache: 20
Processor cache type: Smart Cache
Maximum turbo power: 121
Processor base power: 65
Neural processor unit (NPU): Intel AI Boost
Sparsity support: Yes
Windows Studio effects support: Yes
AI software frameworks supported by NPU: DirectML/ONNX RT/OpenVINO/WebNN/Windows ML
Total processor performance up to: 19
NPU performance up to: 13
Internal memory: 16
Maximum internal memory: 64
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 2 x 8
Memory slots: 4x DIMM
Memory clock speed: 5600
Storage media: SSD
Total storage capacity: 1000
Total SSDs capacity: 1000
Number of SSDs installed: 1
SSD capacity: 1000
NVMe: Yes
SSD interface: PCI Express 4.0
SSD form factor: M.2
Discrete graphics card: Yes
Discrete graphics card model: NVIDIA GeForce RTX 5060
Discrete graphics card memory: 8
Discrete graphics memory type: GDDR7
Ethernet LAN: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 7 (802.11be)
Antenna type: 2x2
Bluetooth: Yes
Bluetooth version: 5.4
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Combo headphone/mic port: Yes
Motherboard chipset: Intel B860
Audio chip: Realtek ALC623
Audio system: High Definition Audio
Product type: PC
Trusted Platform Module (TPM): Yes
Power supply: 500
Certification: RoHS
Width: 211
Depth: 490.4
Height: 414
Weight: 15000
Units per Shipping Box: 1
Unit Calculated Volume: 0.10384
Unit Calculated Weight: 14
